CNC Lathe Machine Features:
This lathe meets the special requirements of users in the petroleum, geological, mining and chemical industries, and in agricultural irrigation and drainage, it is able to cut various straight and taper pipe threads of union joints, drill rods, casting pipes, drain pipes, well castings and water pump pipes more economically and efficiently as compared with the engine lathe,however, it may serve as an engine lathe to cut various metric, with worth and module threads, shafts and disks.
1. The machine is equipped with a tapering unit which can work out a ±1:4 taper.
2. It is able to cut both metric and threads without changing the translating gear.
3. The dripping worm in the apron can protect the mechanisms of the lathe automatically.
4. The guide way is hardened and finely finished.
5. The great power of the machine is competent at heavy load and power cutting.
6. The floor center rest can be moved freely as required by the user.
7. The center rest is provided with an adjustable clamp unit for long pipes, greatly reducing.

High Precision Taper Thread Cutting Pipe Thread CNC Lathe
introduce:
Product Features of CNC pipe Thread Lathes The CNC pipe Thread Lathes,Specially Produced for pipe Thread turning is availabie for the metric and inch cylindcal pipe Thread turning and cone-shaped pipe Thread turning
It is also available for the common lathe turning,boring,interior and exterior conical surface turning, and facing.The application of this kind of lathe covers metallurgy,chemical industry, hydroel-ectric industry,and geologic industry for the process of drill pipe, drill collar,Kelly bar and ferrule, and it is suitable for the process of the oil pipe and steel pipe most.
Structure:
Bed with high rigidity for the sturdy body and widened guide-ways ,and with long life and high precision retentiveness for the twice aging ,hardening ,and grinding.
Headstock strong enough to support the heavy cutting and finish turning for the sturdy structure ,quenched and ground gears ,large spindle ,and precision heavy-duty bearings.
Centralized auto lubrication.
Guide-ways with TSF coated make the friction reduced and the servo performance promoted.
Chuck arrangement both at front end and rear end secures the stability and reliability .
Standard Configuration:
Domestic famous brand Guangzhou CNC system
Domestic wafangdian bearing
Brand-name centralized lubricating system
Domestic brand-name electric tool post
Domestic brand-name ball-screw
Optional:
Other CNC unit :SINUMERIK 808D / FANUC Series Oi-TF
V6 turret, V8 turret
Pneumatic(QK1313/QK1319/QK1322)///Electricchuck(QK1327/QK1335/QK1343)
(with limited chucking range)
Back support center post,Steady rest
Higher accuracy than standard
Chip removal machine

Main Parameters
